Error from On Demand Print Client: Error in View->OnDraw()!

Message

After opening a label in On Demand Print Client, an error dialog box appears displaying the message:

Error in View->OnDraw()!

Explanation

This behavior has been found to occur when a version of On Demand Print Client is installed on a Windows operating system which is not supported by that particular On Demand Print Client version.  For example, if On Demand Print Client version 10.1.1.51 is installed on a computer running the Windows 10 operating system.

Solution

Careful planning must take place when upgrading client and server operating systems. It is not uncommon for client or desktop operating system replacement to outpace server replacement. A supported Loftware Print Server environment requires that the Loftware Print Server version and On Demand Print Client versions match. A situation may arise where a specific version of Loftware Print Server is supported on the server but the matching On Demand Print Client version is not supported on the client system. For example Loftware Print Server version 10.1.1.51 is supported on Windows Server 2008 R2 but On Demand Print Client version 10.1.1.51 is not supported on Windows 10.

  1. Refer to the Loftware Print Server and LabelClosed A label is a design area on the computer screen where a label format is created or edited. Manager Installation Guide which contains a section on Loftware Print Server Client Requirements that lists the supported client operating systems for that specific version.
  2. Refer to the online Loftware Print Server User Guide ( Design 32 > Help > Loftware Print Server User Guide ) which contains a section on client requirements.

Article Number

2017065

Versions

Loftware Print Server 10.x

Environment

On Demand Print Client 10.x installed on unsupported Operating Systems
